Why Us
The Virtual EMI/EMC Laboratory
![https://simyog.com/wp-content/uploads/2021/07/Simyog-Why-us-12x.png](https://simyog.com/wp-content/uploads/2021/07/Simyog-Why-us-12x.png)
![https://simyog.com/wp-content/uploads/2021/08/Simyog-Link_Why-Us.png](https://simyog.com/wp-content/uploads/2021/08/Simyog-Link_Why-Us.png)
Simulation results correlates with Lab Results
Design For EMC
![https://simyog.com/wp-content/uploads/2021/09/Group-1378.png](https://simyog.com/wp-content/uploads/2021/09/Group-1378.png)
Front Loading EMC for first-time pass
Diagnosis For EMC
![https://simyog.com/wp-content/uploads/2021/08/Group-1368-1.png](https://simyog.com/wp-content/uploads/2021/08/Group-1368-1.png)
EMC mitigation to meet compliance
Our Approach
Automated EMC Laboratory Setup
![](https://simyog.com/wp-content/uploads/2021/07/crop-1.png)
EMC Specific Model Libraries
![](https://simyog.com/wp-content/uploads/2021/07/crop-2.png)
Fast 3D Runtime
![](https://simyog.com/wp-content/uploads/2021/07/Group-1342@2x.png)
EMC Diagnosis
![](https://simyog.com/wp-content/uploads/2021/07/Group-1343@2x.png)
Compliance-Scope®
![compliance_scope](https://simyog.com/wp-content/uploads/2021/09/1.jpg)
![compliance_scope](https://simyog.com/wp-content/uploads/2021/09/2.jpg)
![compliance_scope](https://simyog.com/wp-content/uploads/2021/09/3.jpg)
![compliance_scope](https://simyog.com/wp-content/uploads/2021/09/4.jpg)
virtual laboratory for emi/emc
Compliance-Scope®, is a Virtual EMI/EMC laboratory where designers can validate and improve their hardware at an early stage by uploading their design files. The tool also provides diagnosis and suggestions for low-cost fixes at the Printed Circuit Board level.
![](https://simyog.com/wp-content/uploads/2021/07/support-bg.png)
Compliances that we support
Technology
Data Models
Compliance-Scope® employs data-based models for several equipment in the laboratory e.g. injection-clamp model, antenna model, LISN model and operating condition dependent IC-models. These models capture the working of individual elements and are plugged into the Electromagnetic solver environment for a system-level output.
- Injection-Clamp Model.
- Operating Condition Dependent IC-Model.
- LISN Model.
- EMI Reciever Model.
CE and RE LISN Models
![](https://simyog.com/wp-content/uploads/2021/07/Group-1329@2x.png)
Method of Moments: NO Absorbing Boundary
![](https://simyog.com/wp-content/uploads/2021/07/CurrentDensity222x.png)
Physics Based Simulation
These include fast 3D full-wave Electromagnetic solver, 2D Electromagnetic solver based on Multi-conductor Transmission Line (MTL) theory and circuit solver. Based on the laboratory type, Compliance-scope applies custom hybrid solvers such that accuracy is maintained while speeding up the solution process.
- Fast MoM Solver.
- Adaptive Frequency Sweep for EMI/EMC output parameters.
- Hybrid Solvers.
Case Studies
Study of Radiated Emission from an Automotive Touchscreen System – A Simulation Driven Approach
![](https://simyog.com/wp-content/uploads/2021/08/case-study-simyog21.png)
Effect of Cable-bend on CISPR25 CE Current Method
![](https://simyog.com/wp-content/uploads/2021/08/case-study-simyog31.png)
Black-Box DC-DC Integrated Circuit Modeling towards Design for EMC in Automotive Electronics
![](https://simyog.com/wp-content/uploads/2021/08/case-study-simyog41.png)
Model-Based System-Level EMI/EMC Simulation for BCI Pass-Fail Prediction.
![](https://simyog.com/wp-content/uploads/2021/08/case-study-simyog51.png)
